C-Pro 3 micro

c-pro micro is a range of programmable controllers for applications in Refrigeration and Air Conditioning sectors. They are available with integrated user interface or a blind version with a possible remote user interface.

The controllers have several outputs which make it possible to create a flexible, modular, and expandable control devices network.

The variety of available communication ports (RS-485, CAN and USB) and supported communication protocols promote the integration of the controllers in systems.
The application software can be written with the UNI-PRO 3 development environment for programmable controllers.

Installation is on DIN rail, into a control panel.

Technical Features

Programmable controllers c-pro 3 micro c-pro 3 micro+
EPU2B EPU2BR EPU2L EPU2LR EPU2BXP EPU2LXP EPU2LSR EPU2BSR
Version
blind
built-in LED (4+4 digits custom display)
Digital outputs (electromechanical relays; res. A @ 250 VAC)
3 A SPST 6 7 6 7 7 7 7 7
3 A SPDT 2 2
Digital outputs (command for solid state relay)
24 VAC/DC, 0.6 A max 2 2
Power supply
12 VAC not isolated
Analog inputs
PTC/NTC/Pt 1000/0-20 mA/4-20 mA/0-5 V ratiometric/0-10 V 3 3 3 3 6 6 6 6
PTC/NTC/Pt 1000 3 3 3 3 3 3 3 3
Digital inputs (for NA/NC contact)
optoisolated 24 VAC/DC 50/60 Hz contacts 3 3 3 3 7 7 7 7
optoisolated 24 VAC/DC 2 KHz contacts 2 2 2 2 2 2 2 2
Analog outputs
PWM/0-10 V 2 2 2 2 2 2 2 2
0-10 V 2 2 2 2
0-20 mA/4-20 mA/0-10 V 1 1 1 1 2 2 2 2
Dimensions
DIN modules 4 4 4 4 4 4 4 4
Connections
Micro-Fit connectors
removable spring terminal blocks
removable screw terminal blocks
Communication ports
MODBUS master RS-485 1 1 1 1
MODBUS slave RS-485 1 1 1 1 1 1
CANBUS CAN 1 1 1 1 1 1 1 1
USB 1 1 1 1 1 1 1 1
Other features
real time clock
