| Sensor type* | NS 110x(K) | NS 111x(K) | NS 112x(K) | NS 310x(K) | NS 311x(K) |
| Type of sensing element | Ni 1000/5000 | Ni 1000/6180 | Ni 891 | Ni 10000/5000 | Ni 10000/6180 |
| Measuring range | -50 to 100°C | ||||
| Maximum measuring | 1 mA | 1 mA | 1 mA | 0.3 mA | 0.3 mA |
| DC current | |||||
*(K – with connector)
| Sensor type* | NS 113x(K) | PTS 110x(K) | PTS 210x(K) | PTS 310x(K) | HS 110x(K) |
| Type of sensing element | T1 = Ni 226 | PT 100/3850 | PT 500/3850 | PT 1000/3850 | termistor NTC 20 kΩ |
| Measuring range | -50 to 100 °C | ||||
| Maximum measuring | 0.7 mA | 3 mA | 1.5 mA | 1 mA | 0.3 mW *) |
| DC current | |||||
*(K – with connector)
| Sensor type* | NS 510A(K) | NS 710x(K) | Note |
| Type of sensing element | Pt 1000/3850 | PT1000/3850 | – |
| Output signal | 4 to 20 mA | 0 to 10 V | – |
| Measuring renges | -30 to 60 °C | -30 to 60 °C | Ambient temperature arround the connection -30 to 70 °C |
| 0 to 35 °C | 0 to 35 °C | ||
| 0 to 100 °C | 0 to 100 °C | ||
| 0 to 150 °C | 0 to 150 °C | ||
| Power supply (U) | 11 to 30 V DC | 15 to 30 V DC | Recommended value 24 V DC |
| Load resistance Rz | 150 Ω for power supply 12 VDC | > 10kΩ | – |
| 700 Ω for power supply 24 VDC | |||
| Output signal | > 24 mA | > 10.5 mA | – |
| – sensing elements break | |||
| Output signal | < 3.5 mA | ~ 0 V | – |
| – sensing element short |
*(K – with connector)
| Other Parameters | |
| Accuracy class | Ni sensing elements: B class, t = ± (0.4 + 0.007t), for t ≥ 0; t = ± (0.4 + 0.028|t|), for t ≤ 0 in °C; |
| Pt sensing elements: B class according EN 60751, t = ± (0.3 + 0.005|t|) in °C | |
| NTC 20 kΩ: ± 1 °C for the range 0 to 70 °C | |
| Measuring error | NS 510A ± 1 °C (based on air flow speed) |
| NS 510A(K), NS 710x(K) | NS 710A 0,6 % for range with span; min. 0,5 °C |
| Sensors connection | according to the wiring diagram |
| Standard length of the stem (version A) | for resistance output and for output 0 to 10 V : 25 mm |
| for output 4 to 20 mA : 50 mm | |
| Time response | τ0.5 < 9 s (in air flow at 1m s-1) – version A |
| τ0.5 ≤ 30 s (in air flow at 1m s-1) – version B | |
| Recommended wire cross section | 0.35 to 1.5 mm2 |
| – sensors with grommet | |
| Type of connector in the head | RSFM4 – Lumberg |
| – sensor with connector | |
| Insulation resistance | > 200 MΩ at 500 V DC, 25° ± 3 °C; humidity < 85 % |
| Ingress protection | IP 65 in accordance with EN 60529 |
| Material of the stem | stainless steel DIN 1.4301 – version A |
| Material of the connection head | POLYAMIDE |
| Operating conditions | ambient temperature: -50 to 100 °C; -30 to 70 °C with a converter |
| relative humidity: max. 100 % (at the ambient temperature 25 °C) | |
| atmospheric pressure: 70 to 107 kPa | |
| Weight | approximately 0.15 kg |
